Outdoor Heavy Duty Steel Grating Car Wash Road Sidewalk Storm Ditch Trench

  • Outdoor Heavy Duty Steel Grating Car Wash Road Sidewalk Storm Ditch Trench
  • Outdoor Heavy Duty Steel Grating Car Wash Road Sidewalk Storm Ditch Trench
Place of Origin Hebei
Brand Name Zhuote
Certification ISO9001-2015
Model Number 255/40/50
Minimum Order Quantity 10 piece
Price Can discuss
Packaging Details Steel belt packaging
Delivery Time 7-10work days
Payment Terms L/C, T/T
Supply Ability 800 Square meters/day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Steel, Q235, SS316 Product Name Steel Grating, Hot-dip Galvanized Heavy Duty Steel Grating For Water Well Cover, Hot Dip Galvanized Mild Steel Bar Grating And Metal Grid Weight
Length Max 6000mm, 0.8m, Customer's Demand, 2m Height 25~40mm
Keywords Steel Grating, Swimming Pool Drain Grating Type Plain Bar Grating, Steel Plate
Width 600-1250mm, 70-600mm Surface Hot Dipped Galvanized, Painted, Galvanized
Highlight

car wash heavy duty steel grating

,

painted heavy duty steel grating

,

drainage covers heavy duty grating weight
Leave a Message
Product Description



Outdoor Heavy Duty Car Wash Road Sidewalk Storm Ditch Trench Drainage Grating Covers



Steel Grating Specification Available:

Bearing bar:25mmx3mm,30mmx2mm,30mmx5mm,35mmx5mm

Cross rod:6mm-8mm twisted rod

Bearing bar pitch:30-40mm

Cross rod spacing:100mm

Panel size:100*100cm, 100*300cm,914mm width*5.8m long.

Surface:hot dip galvanized/ stainless steel/painting.

Material:Q235 iron steel.



Steel Grating Feature

1) The steel grating can reduce the supportive material, investment, save workman and time.

2) It can be used in almost all applications.

3) Lightweight and economical.

4) Low maintenance cost, because the surface will be galvanized, the anti-corrosion is 15~30 times than ungalvanized.



Application:

Heavy duty steel grating is widely used in many areas:

a. It can be used as stair tread grating.

b. It can be used in the municipal engineering as drainage trench covers to drain water and keep ground dry.

c. It can be used in the port, parking lot, farmland and other places as platform walkway grating for pedestrian and vehicles access & passing.







Item Description
Bearing Bar

25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc

I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc

US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'', 1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1 1/2''x1/8'' etc
Bearing Bar Pitch

12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc

US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
Material Grade

ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400,

Mild steel & Low carbon steel, etc
Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar
Standard

China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),

UK: BS4592-1987, Australia: AS1657-1985,

Germany: DIN24537-1-2006, Japan :JIS


Outdoor Heavy Duty Steel Grating Car Wash Road Sidewalk Storm Ditch Trench 0Outdoor Heavy Duty Steel Grating Car Wash Road Sidewalk Storm Ditch Trench 1





Service
1. 24 hours service will be always available.
2. We can customize the product according to your design.
3. We follow the principle – be honest, professional and efficient.
4. Perfect after-sales service.
5. If you are interested in our products or related products, please contact us.


FAQ
1. who are we?
A.We are based in Hebei, China,sell to Domestic Market(50.00%),North America(20.00%),Western Europe(10.00%),
Southeast Asia(5.00%),Eastern Europe(5.00%),South Asia(2.00%),Mid East(2.00%),Oceania(2.00%),Southern
Europe(2.00%),Eastern Asia(1.00%),Northern Europe(1.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
A.Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
A.Mesh; Steel Grating; Filtration Equipment; Fence Netting

4. why should you buy from us not from other suppliers?
A.1. We are a professional manufacturer
2. We have very competitive prices and strict quality control to provide the best service
3. We provide one-stop service to assist you to develop together with us

5.How about your delivery time?
A.Generally, it will take 5 to 10 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
