Construction Material Heavy Duty Steel Grating Galvanized Low Carbon

  • Construction Material Heavy Duty Steel Grating Galvanized Low Carbon
  • Construction Material Heavy Duty Steel Grating Galvanized Low Carbon
  • Construction Material Heavy Duty Steel Grating Galvanized Low Carbon
  • Construction Material Heavy Duty Steel Grating Galvanized Low Carbon
Place of Origin Hebei
Brand Name Zhuote
Certification ISO9001-2015
Model Number 325/30/100
Minimum Order Quantity 69 piece
Price Can discuss
Packaging Details Steel belt packaging
Delivery Time 5 - 8work days
Payment Terms L/C, T/T
Supply Ability 1500 Square meters/day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Steel, Galvanized Sheet, Aluminium, SS316L, A36 Product Name Steel Grating, Hot-dip Galvanized Heavy Duty Steel Grating For Water Well Cover, Hot Dip Galvanized Mild Steel Bar Grating And Metal Grid Weight, Hot Dipped Glavanized Drain Steel Grating, Fibre Reinforced Polymer Grating
Color Silver, Black, Silver Or As Your Requirement, Based On Customer's Requirement, Matt White. Silvery Type Plain Bar Grating, Steel Plate, 19-w-4, I Type Or Serrated, 40/50
Length As Required, 1-12m, 100-3000mm, Max 6000mm Grating Size 3'x20', 1000x1000, 1000x6000mm And All, 3x30', 1000x5800mm
Highlight

construction heavy duty steel grating

,

low carbon heavy duty steel grating

,

serrated heavy duty bar grating
Leave a Message
Product Description

Petroleum equipment platform construction material galvanized heavy steel grating



Product Description



1.Material :Low carbon steel, stainless steel, aluminum alloy
2.Shape and specification
Surface Treatment: Untreated, Painting or Hot Dipped Galvanizing or as requrest
3.Types of Steel Grating: Plain/smooth type, I type ,Serrated/teeth type.
4.Cross bars shape: square bars, twisted square bars,round bars


Bearing Bar Width: 25mm, 30mm, 32mm, 40mm, 60mm, 80mm, etc

Bearing Bar Thickness: 2.5mm, 3mm, 4mm, 5mm, etc

Bearing Bar Pitch: 30mm, 40mm, 50mm, etc

Cross Bar Diameter: 5mm, 6mm, 8mm, etc.

Surface treatment: Hot dip galvanized, Untreatd, Stainless steel , etc



Product Application
It is widely used as flooring, catwalk, mezzanines/decking, stair tread, fencing, ramp,dock, trench cover, drainage pit cover, maintenance platform, pedestrian/crowded pedestrian in factories, workshops, motor rooms,trolley channels, heavy loading areas, boiler equipment and heavy equipment areas, etc.

No. Item Description
1 Bearing bar

25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc

I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc

US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'', 1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1 1/2''x1/8'' etc
2 Bearing bar pitch

12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc

US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
3 Cross bar 5*5,6*6,8*8mm(twisted bar or round bar)
4 Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
5 Material Grade

ASTM A36,A1011,A569,Q235,S275JR,SS304,SS400,

Mild steel & Low carbon steel,etc.
6 Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
7 Flat bar type Plain,Serrated(tooth-like),I bar (I section)
8 Standard

China:YB/T 4001.1-2007,USA:ANSI/NAAMM(MBG531-88),

UK:BS4592-1987,Australia:AS1657-1985,

Germany:DIN24537-1-2006,

Japan:JJS.



Construction Material Heavy Duty Steel Grating Galvanized Low Carbon 0Construction Material Heavy Duty Steel Grating Galvanized Low Carbon 1Construction Material Heavy Duty Steel Grating Galvanized Low Carbon 2



Our services

1. Any enquiry will be replied within 12 hours.

2.Sample production and delivery service can be provided, as for any information about the sample or any specific requirements for the sample, please contact us via telephone , mail or online trade manager.

3.OEM/ODM is available. Printing logo on customized products.Customized design and material. Customized packing for your products.

4.Before-sale and after-sale service. All products have been strictly quality test in our factory before packing.



FAQ
1. who are we?
We are based in Hebei, China, start from 2014,sell to Domestic Market(50.00%),North America(20.00%),Southern Europe(10.00%),Eastern Europe(10.00%),South America(10.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
steel grating,FRP grid,Guardrail,sound barrier,filter mesh.

4. why should you buy from us not from other suppliers?
The company insists on taking improving product quality as the goal, taking excellent after-sales service as the purpose, carrying out ISO 9001 standard to strengthen the internal management of the enterprise, and pursuing the product quality of excellence
